hydraulic lift platform (vrc c
floor to floor car lift qsjy3-4b
product usage

applicable to 4s shops, large repair shops, etc. the car is vertically lifted between floors, and can also be used for cargo lifting or three-dimensional parking.

parameter
  • model number
  • qsjy3-4b
  • lift capacity(t)
  • 1-8
  • min lift(mm)
  • 200
  • lift high(mm)
  • 3000-13000
  • pressure(mpa)
  • 16
  • motor power(kw)
  • 4/5.5
  • input voltage(v)
  • 380

high-precision hydraulic drive with smooth lifting, simple operation and low failure rate

high-strength chain pulling, bearing without extension, long service life, large safety factor

double chain lifting for safer and more reliable lifting

adjustable screw to ensure platform level and smooth lifting of the car

large-capacity pumping station with fast lifting speed and low running noise

novel and beautiful design, sturdy and durable structure

make full use of limited space to create more value
